RM series 5-channel 100V mixer amplifier with Bluetooth®
Rack-mountable 5-channel mixer amplifier for commercial installations. Media player with SD, USB, FM and Bluetooth. XLR, mic/line and RCA inputs. Powers 100V or 8 ohm mono speakers.
- 2U 19" rack mountable (rack ears supplied)
- XLR input with switchable +20V phantom power – ideal for condenser microphones and paging microphones with chimes
- 2 x mic/line inputs, 2 x RCA line inputs, and 1 x RCA line output
RM series 5-channel 100V mixer amplifier with Bluetooth®
A rack-mountable 5-channel mixer amplifier, tailored to commercial sound installations, that can either be used as a 100V line amplifier or a standard low-impedance amp. Versatile input options include XLR (with switchable phantom power), mic/line jack, and RCA line. Powers 100V or 8 ohm mono speakers. Features an inbuilt FM radio tuner, front-mounted SD and USB ports, and Bluetooth connectivity, all controlled via an integrated media player for hassle-free playback. A switchable ‘voiceover’ feature automatically lowers the background music volume when a signal is detected via mic input 1.
- 2U 19" rack mountable (rack ears supplied)
- XLR input with switchable +20V phantom power – ideal for condenser microphones and paging microphones with chimes
- 2 x mic/line inputs, 2 x RCA line inputs, and 1 x RCA line output
- Switchable ‘voiceover’ feature
- Inbuilt media player with SD, USB and Bluetooth inputs and integrated FM radio tuner
- 100V line or 8 ohm speaker output
- Option for mains or 24Vdc power
Specification : Common
- Power supply 110/240Vac, 50/60Hz (IEC)
- DC power 24Vdc (screw terminals)
- Inputs Mic XLR, 2 x mic/line jack, 2 x RCA line
- Input sensitivity : mic 1 (balanced) -53dBV
- Input impedance : mic 1 5k Ohms
- Input sensitivity : line (unbalanced) -15dBV (-18.5dBV line 5)
- Input impedance : inputs 2-5 1k Ohms
- Line output RCA
- Controls Mic1, mic/line2+3, line4+5, bass, treble, master volume
- Equalizer : bass 100Hz ±10dB
- Equalizer : treble 10kHz ±10dB
- Rear panel switches Phantom, Vox, Mic/Line (2 + 3)
- Phantom power +20V (mic 1 input)
- Audio source USB/SD player, FM tuner and Bluetooth receiver
- Bluetooth version 2.0
- THD <1.0%
- Dimensions 433 x 320 x 89mm
Specification : Versions
| 953.113UK | 953.116UK | 953.114UK | 953.115UK | |
|---|---|---|---|---|
| Output power | 60Wrms | 360Wrms | 120Wrms | 240Wrms |
| Speaker outputs | 100V / 8 Ohms / COM terminals | 4 x 100V zone / 8 Ohms / COM terminals | 100V / 8 Ohms / COM terminals | 4 x 100V zone / 8 Ohms / COM terminals |
| Speaker switching | N/A | Zones 1, 2, 3, 4, All | N/A | Zones 1, 2, 3, 4, All |
| Weight | 5.98kg | 12.68kg | 8.36kg | 9.62kg |
Trade information
| 953.113UK | 953.114UK | 953.115UK | 953.116UK | |
|---|---|---|---|---|
| Barcode / EAN | 5015972176481 | 5015972176504 | 5015972176528 | 5015972191644 |
| Package type | Box Printed | Box Printed | Box Printed | Box Printed |
| Package dimensions | 535 x 390 x 133mm | 535 x 390 x 133mm | 535 x 390 x 133mm | 460 x 525 x 125mm |
| Package weight | 5.98kg | 8.36kg | 9.62kg | 14.98kg |
| Package quantity | 1 unit | 1 unit | 1 unit | 1 unit |
| Carton dimensions | 448 x 550 x 291mm | 448 x 550 x 291mm | 550 x 405 x 291mm | 475 x 540 x 148mm |
| Carton weight | 11.96kg | 16.72kg | 19.24kg | 15.50kg |
| Carton quantity | 2 packages | 2 packages | 2 packages | 1 package |
In the box
The box for this item contains :
- 100V mixer-amplifier
- Rack-mounting ears & hardware
- IEC mains lead
